Nevsbye ABS 3D Printing Filament (1.75mm, 1KG Spool) delivers exceptional mechanical strength, heat resistance,unbeatable impact tolerance and durability –designed for functional prototypes, automotive parts,home appliance spare parts and industrial applications where failure is not an option. Trusted by professionals for its rugged reliability.
Why Choose Nevsbye ABS Filament?
✔ Superior Impact Resistance, Industrial-Grade Performance – 95°C Heat Resistance, survives engine bays, hot enclosures & summer heat. Designed to withstand stress and shocks, perfect for engineering and mechanical components. Stronger than standard ABS/PLA.
✔ Built for Tough Environments, Chemical & Moisture Resistant - Withstands drops, collisions & repetitive stress. Ideal for automotive fluids, outdoor & wet applications.
✔ Excellent Thermal Stability – Heat deflection temperature of 95°C and glass transition temperature up to 108.9°C, ensuring structural integrity in demanding conditions.
✔ Dimensional Accuracy – Mold shrinkage rate of just 0.4–0.9%, keeping your prints precise and true to design.
✔ Smooth Printability – Melt flow rate of 15g/10min, with optimized settings for fast and stable printing.Smooth layers, zero bubbles.
Wide Applications:
➤ Functional Engineering: Gear housings, motor mounts, drill jigs
➤ Automotive: Dashboard components, intake manifolds, fluid caps
➤ Industrial: Machinery fittings, high-temp tools, factory fixtures
➤ Consumer Goods: Tool handles, drone frames, outdoor enclosures
➤ Post-Processing: Acetone-vapor smoothing for glossy finishes
Key Features
- Superior Heat Resistance
- Industrial-Grade Toughness
- Unbeatable impact tolerance
- Chemical & Moisture Resistant
- Precision Engineered
Specifications
| ABS Properties | |
| Product Name | ABS (Acrylonitrile Butadiene Styrene) |
| Tensile Strength (X-Y) | 42 MPa (ISO527/2) |
| Young’s Modulus (X-Y) | 2270 MPa (ISO527/2) |
| Elongation at break (X-Y) | 7.8% (ISO527/2) |
| Flexural Strength (X-Y) | 55 MPa (ISO178) |
| Flexural Modulus (X-Y) | 1829 MPa (ISO178) |
| (X-Y) IZOD Impact Notched | 25 KJ/m² (ISO180) |
| Shore hardness | 85 HA/HD (ISO868) |
| Heat Deflection Thermal (HDT) | 95℃ (ISO75) |
| Glass Transition(Tg) | 108.9℃ (ISO11357-3) |
| Melting Point | 132℃ (ISO11357-3) |
| @5%Decomposition Temp. | ≥415℃ (ISO11358) |
| Vicat Softening Temp. | 86℃ (ISO306) |
| Mold Shrinkage | 0.4-0.9% (ISO294) |
| Coefficient of Thermal Exp. | 60.7 ㎛ (m·℃) |
| Melt Flow Rate | 15 g/10min (ISO1133) |
| Density | 1.02 g/cm³ (ISO1183) |
| Volume Resistivity | 6.75*10^14 ohm-cm (IEC60093) |
| Flammability | HB Class |
| Chemical Resistance | |
| Item | Class |
| Weak Acid (pH 3-6) | Excellent |
| Strong Acid (pH<3) | Average |
| Weak Bases (pH 8-10) | Excellent |
| Strong Bases (pH >10) | Excellent |
| Deionized Water | Excellent |
| Alcohol | Good |
| Ketone | Poor |
| Petroleum Fuels | Good |
| Ester | Average |
| Recommended Printing Parameters | ||
| Parameters | Range | |
| Nozzle Print Temp. | Nozzle Print Temp. | Speed |
| 250-260℃ | 50-100mm/s | |
| 260-280℃ | 100-200mm/s | |
| Print Platform Temp. | 80-100℃ | |
| Print Platform Material | Regular | |
| Print Platform Treatment | GLUE | |
| Cool Fan | Open | |
| Raft Distance | 0.4-0.6mm | |
| Retraction Distance | 0.8-1.2mm | |
| Retraction Speed | 30-40mm/s | |
| Room Temp. | Normal | |
| Support Material | PVA | |
| Drying Temp. | 50℃ | |
| Filament Diameter | 1.75±0.03mm | |
| Net weight | 1Kg/2.2lb | |
| Gross Weight | 1.38Kg/3.04lb | |
| Packing Size | 210x210x70mm | |
